G-400 Horizontal Angle Metal Cutting Bandsaw Machine

G-400 product features
1.This machine adopts and absorbs the performance characteristics of similar foreign sawing machines, hydraulic balance cylinder, high-strength balance spring and hydraulic stepless speed regulation.
2.The material cut by the sawing machine does not move, and the saw frame can rotate 0-45 degrees forward or 0 to 60 degrees in the reverse direction, which is suitable for sawing various angle steels, round steels, rectangular pipes, etc. with angle requirements.
3.The bed at the clamping part can move forward and backward to facilitate clamping of materials.
This machine can also be equipped with CNC cornering and automatic feeding system to achieve automatic cutting.

Color:	customer request
Availability:

Quantity:



Inquire Add to Basket

Model:
G-400
Brand:
JEPPS

Product Description

G-400-5

G-400 product features

1.This machine adopts and absorbs the performance characteristics of similar foreign sawing machines, hydraulic balance cylinder, high-strength balance spring and hydraulic stepless speed regulation.
2.The material cut by the sawing machine does not move, and the saw frame can rotate 0-45 degrees forward or 0 to 60 degrees in the reverse direction, which is suitable for sawing various angle steels, round steels, rectangular pipes, etc. with angle requirements.
3.The bed at the clamping part can move forward and backward to facilitate clamping of materials.
This machine can also be equipped with CNC cornering and automatic feeding system to achieve automatic cutting.

G-400-3

Project	G-260	G-330	G-400
sawing capacity	0°Ф260mm W260xH260mm	0°Ф330mm W460xH305mm	0°Ф400mm W500xH400mm
	±45°Ф260mm W60xH200mm	±45°Ф305mm W305xH305mm	±45°Ф400mm W400xH400mm
		﹣60°Ф220mm W220xH305mm
Saw band specification	3505x27x0.9mm	4115270.9mm	4800341.1mm
Band speed	40/60/80 by tower wheel	40/60/80m/min Cone speed regulation	40/60/80m/min Cone speed regulation
main motor power	2.2kw	2.2kw	4.0kw
Hydraulic motor power	0.42kw	0.42kw	0.75kw
Water pump motor power	0.04kw	0.04kw	0.09kw
Work clamping method	hydraulic	hydraulic	hydraulic
Saw band tensioning method	Manual	Manual	Manual
Main transmission structure	turbine	turbine	turbine
Feeding method	Roller auxiliary feeding	Roller auxiliary feeding	Roller auxiliary feeding
Machine weight	700kg	950kg	1500kg
Machine size	1700L1200W1500H	1900L900W1550H	2000L1200W1500H
