CD-400/600
JEPPS
Processed Product Display
Features
Compact Structure, Space-Saving Design
小巧机身设计，占地面积小，特别适合小型车间、创客空间或初创企业，有效节约生产场地成本。
Cost-Effective & High Value
以合理的投入获得可靠性能，显著降低设备采购与运营成本，帮助企业在短时间内实现投资回报。
Easy to Operate
支持手动/半自动模式切换，界面直观，学习曲线短，减少员工培训时间与人力成本。
Multi-Material Compatibility
可加工铝、铜、不锈钢、碳钢等多种薄板金属材料，满足多样化产品制造需求。
Stable & Precise Forming
配备高精度主轴与可调夹具，确保成形尺寸一致、表面光洁度高，减少二次加工。
Energy-Saving Design
采用高效节能电机与优化传动系统，降低长期运行电费，符合绿色制造理念。
Customizable Configuration
可根据工件形状、尺寸及工艺要求，灵活选配专用模具、尾顶及其他辅助工装，提升生产效率与适应性。
| 型号/model | CD-400-A | CD-600-A |
| 系统配置(System Configuration) | 谷戈Gu Ge | |
| 伺服电机(Servo Motor) | 维控wecon | 维控wecon |
| 刀架形式(Tool holder form) | 固定刀架+2套旋转刀架 Fixed tool holder +2 sets of rotating | |
| 刀架数量(Number of tool holders) | 3 | |
| 最大过料直径(Maximum feeding diameter) | 450mm | 650mm |
| 最大加工厚度(Maximum processing thickness) | 铁1.5mm以内 Iron within 1.5mm | 铁2mm Iron with 2mm |
| X轴最大行程(X-axis maximum travel) | 350mm | 400mm |
| Y轴最大行程(Maximum travel of Y axis) | 225 | 325 |
| 加工件长度(Length of workpiece) | 350 | 500 |
| 主轴转速(Spindle speed) | 10-2800转/分钟 10-2800 rpm/min | |
| 主轴端面到尾座端面跨距(Distance from spindle end to tailstock end) | 600mm | 1000mm |
| 尾座调节行程(Tailstock adjustment stroke) | 400mm | 500mm |
| 主轴变频电机功率(Spindle variable frequency motor power) | 7.5kw | 11kw |
| 机器重量(Machine weight) | 1800kg | 2400kg |
| 料位支撑架吹气挡板 (Level support frame air blowing baffle) | 有 have | |
| 设备尺寸(Device size) | 2400x1600x1350 | 3200x1900x1550 |
主要用途（Applications / Uses）
灯饰制造
Lighting Fixture Manufacturing
用于生产灯具反光罩、灯杯等圆形或锥形金属件，适用于家居、商业及工业照明领域。
Used for producing lamp reflectors, lamp cups, and other round or conical metal parts for residential, commercial, and industrial lighting.
厨具生产
Cookware Production
制造锅具、盆类等金属外壳，满足厨房用具的外观与功能性需求。
Manufacturing pots, pans, and other metal shells for kitchenware, meeting both aesthetic and functional requirements.
工艺品与装饰品
Arts, Crafts & Decorative Items
制作金属花瓶、艺术造型件等创意产品，广泛用于室内外装饰与礼品市场。
Create metal vases, artistic shapes, and other creative products for indoor/outdoor decoration and gift markets.
工业零部件
Industrial Components
加工压力容器封头、管端成型件等关键部件，应用于化工、能源及机械设备行业。
Form pressure vessel heads, tube-end shapes, and other critical components for chemical, energy, and mechanical equipment industries.
原型与小批量生产
Prototyping & Small-Batch Production
支持新产品打样与研发测试，帮助企业快速验证设计方案并进入市场。
Ideal for new product prototyping and R&D testing, enabling fast verification of designs and market entry.
教育与培训
Education & Training
作为职业技术学校金工实训设备，培养学生的实际操作能力与金属成型工艺认知。
Used as metalworking training equipment in vocational schools to develop students’ hands-on skills and understanding of metal forming processes.
Other Product
What do we offer?
Like almost all metal spinning machine manufacturers, we design and produce a range of spinning machines with different main parameters to meet customer needs. These spinning machines can save labor costs and improve the quality of the final product. They can process materials such as carbon steel, stainless steel, aluminum, copper, and brass of specific thicknesses. The PLC system controls the operation accuracy without operator intervention. We offer powerful CNC metal spinning machines equipped with multiple tools and optional additional accessories. Such a tool set is sufficient to complete various processes such as trimming, rolling, and flanging. A variety of shapes can be processed, such as cylinders, rings, cones, hemispheres, and parabolas. We also offer customization options. Product weights range from 600 kg to 4000 kg.
This metal processing method is both simple and complex. Spinning is a process that can only be accomplished with carefully designed machines. The spinning machines we offer allow you to easily achieve fine processing results. If you want to buy the right spinning machine at the best price, please consider our metal spinning machines on special offer.
